`mwbenchr` API Schema Documentation

Overview

This document provides a complete schema of all mwbenchr functions, their parameters, return types, and the underlying REST API endpoints they access.

API overview

Function Categories

mwbenchr
├── Client Management
│   ├── mw_rest_client()
│   └── print.mw_rest_client()
├── Study Functions
│   ├── get_study_summary()
│   ├── get_study_factors()
│   ├── get_study_metabolites()
│   └── get_study_data()
├── Compound Functions
│   ├── get_compound_by_regno()
│   ├── get_compound_by_pubchem_cid()
│   ├── get_compound_classification()
│   └── download_compound_structure()
├── RefMet Functions
│   ├── get_refmet_by_name()
│   ├── standardize_to_refmet()
│   └── get_all_refmet_names()
├── Search Functions
│   ├── search_metstat()
│   └── search_by_mass()
├── Mass Spectrometry
│   └── calculate_exact_mass()
└── Utilities
    ├── response_to_df()
    ├── flatten_entry()
    └── list_endpoints()

1. Client Management

`mw_rest_client()`

Purpose: Initialize REST client for API interactions

Parameters:

mw_rest_client(
  base_url = "https://www.metabolomicsworkbench.org/rest",  # Character
  cache = FALSE,                                            # Logical
  cache_dir = tempdir(),                                   # Character
  timeout = 30                                             # Numeric
)

Returns: S3 object of class "mw_rest_client"

Structure:
├── base_url    : Character - API base URL
├── cache       : Logical - Caching enabled?
├── cache_dir   : Character - Cache directory path
└── timeout     : Numeric - Request timeout (seconds)

REST Endpoint: N/A (local object creation)

2. Study Functions

`get_study_summary()`

Purpose: Retrieve study metadata and summary information

Parameters:

get_study_summary(
  client,                    # mw_rest_client object
  study_id = "ST",          # Character - Study ID or "ST" for all
  format = "json"           # Character - "json" or "txt"
)

REST Endpoint: GET /study/study_id/{study_id}/summary[/{format}]

Returns: - JSON format: Tibble with columns:

├── study_id          : Character
├── study_title       : Character
├── study_type        : Character
├── institute         : Character
├── department        : Character
├── last_name         : Character
├── first_name        : Character
├── email             : Character
├── phone             : Character
├── submit_date       : Character (YYYY-MM-DD)
├── study_summary     : Character
└── [additional metadata columns]

TXT format: Character string

`get_study_factors()`

Purpose: Get experimental design factors (sample metadata)

Parameters:

get_study_factors(
  client,         # mw_rest_client object
  study_id        # Character - Study ID
)

REST Endpoint: GET /study/study_id/{study_id}/factors

Returns: Tibble with experimental factors

├── local_sample_id   : Character
├── sample_id         : Character
├── subject_id        : Character
├── factor_name       : Character
├── factor_value      : Character
└── [study-specific factor columns]

`get_study_metabolites()`

Purpose: Get list of metabolites measured in a study

Parameters:

get_study_metabolites(
  client,         # mw_rest_client object
  study_id        # Character - Study ID
)

REST Endpoint: GET /study/study_id/{study_id}/metabolites

Returns: Tibble with metabolite information

├── metabolite_id     : Character
├── metabolite_name   : Character
├── refmet_name       : Character
├── pubchem_cid       : Character
├── kegg_id           : Character
├── other_id          : Character
├── other_id_type     : Character
└── ri                : Numeric (retention index)

`get_study_data()`

Purpose: Get complete data matrix for a study

Parameters:

get_study_data(
  client,         # mw_rest_client object
  study_id        # Character - Study ID
)

REST Endpoint: GET /study/study_id/{study_id}/data

Returns: Tibble with metabolite data across samples

├── study_id          : Character
├── analysis_id       : Character
├── analysis_summary  : Character
├── metabolite_name   : Character
├── metabolite_id     : Character
├── refmet_name       : Character
├── units             : Character
└── [sample columns]  : Numeric - One column per sample

3. Compound Functions

`get_compound_by_regno()`

Purpose: Retrieve compound information by registry number

Parameters:

get_compound_by_regno(
  client,                    # mw_rest_client object
  regno,                     # Character/Numeric - Registry number
  fields = "all",           # Character - Fields to return
  format = "json"           # Character - "json" or "txt"
)

REST Endpoint: GET /compound/regno/{regno}/{fields}[/{format}]

Available Fields: “all”, “name”, “systematic_name”, “formula”, “pubchem_cid”, “inchi_key”, “smiles”

Returns: Tibble with compound information

├── regno             : Character
├── name              : Character
├── systematic_name   : Character
├── formula           : Character
├── pubchem_cid       : Character
├── inchi_key         : Character
├── smiles            : Character
├── iso_smiles        : Character
└── [additional fields depending on 'fields' parameter]

`get_compound_by_pubchem_cid()`

Purpose: Retrieve compound information by PubChem CID

Parameters:

get_compound_by_pubchem_cid(
  client,                    # mw_rest_client object
  cid,                       # Character/Numeric - PubChem CID
  fields = "all",           # Character - Fields to return
  format = "json"           # Character - "json" or "txt"
)

REST Endpoint: GET /compound/pubchem_cid/{cid}/{fields}[/{format}]

Returns: Same structure as get_compound_by_regno()

`get_compound_classification()`

Purpose: Get taxonomic classification hierarchy for a compound

Parameters:

get_compound_classification(
  client,         # mw_rest_client object
  id_type,        # Character - "regno", "pubchem_cid", etc.
  id_value        # Character/Numeric - Identifier value
)

REST Endpoint: GET /compound/{id_type}/{id_value}/classification

Returns: Tibble with classification hierarchy

├── kingdom           : Character
├── super_class       : Character
├── class            : Character
├── sub_class        : Character
├── direct_parent    : Character
└── molecular_framework : Character

`download_compound_structure()`

Purpose: Download molecular structure files

Parameters:

download_compound_structure(
  client,                    # mw_rest_client object
  id_type,                   # Character - Identifier type
  id_value,                  # Character/Numeric - Identifier value
  format = "molfile"        # Character - "molfile" or "sdf"
)

REST Endpoint: GET /compound/{id_type}/{id_value}/{format}

Returns: Character string containing structure file content

4. RefMet Functions

`get_refmet_by_name()`

Purpose: Get RefMet information for a metabolite

Parameters:

get_refmet_by_name(
  client,                    # mw_rest_client object
  name,                      # Character - RefMet name
  fields = "all"            # Character - Fields to return
)

REST Endpoint: GET /refmet/name/{name}/{fields}

Available Fields: “all”, “name”, “formula”, “exactmass”, “pubchem_cid”, “inchi_key”, “smiles”

Returns: Tibble with RefMet information

├── refmet_name       : Character
├── formula           : Character
├── exactmass         : Numeric
├── pubchem_cid       : Character
├── inchi_key         : Character
├── smiles            : Character
├── super_class       : Character
├── main_class        : Character
└── sub_class         : Character

`standardize_to_refmet()`

Purpose: Convert metabolite name to RefMet standard

Parameters:

standardize_to_refmet(
  client,         # mw_rest_client object
  name            # Character - Metabolite name to standardize
)

REST Endpoint: GET /refmet/match/{name}/name

Returns: Tibble with standardization result

├── input_name        : Character
├── refmet_name       : Character
├── formula           : Character
├── exactmass         : Numeric
└── pubchem_cid       : Character

`get_all_refmet_names()`

Purpose: Retrieve all RefMet standardized names

Parameters:

get_all_refmet_names(
  client          # mw_rest_client object
)

REST Endpoint: GET /refmet/name

Returns: Tibble with all RefMet names

├── refmet_name       : Character
├── pubchem_cid       : Character
├── exactmass         : Numeric
└── formula           : Character

5. Search Functions

`search_metstat()`

Purpose: Search studies using multiple criteria

Parameters:

search_metstat(
  client,                    # mw_rest_client object
  analysis_type = "",        # Character - "LCMS", "GCMS", "NMR", etc.
  polarity = "",            # Character - "POSITIVE", "NEGATIVE"
  chromatography = "",      # Character - "HILIC", "RP", etc.
  species = "",             # Character - "Human", "Mouse", "Rat", etc.
  sample_source = "",       # Character - "Blood", "Urine", "Tissue", etc.
  disease = "",             # Character - Disease/condition
  kegg_id = "",             # Character - KEGG compound ID
  refmet_name = ""          # Character - RefMet metabolite name
)

REST Endpoint: GET /metstat/{analysis_type};{polarity};{chromatography};{species};{sample_source};{disease};{kegg_id};{refmet_name}

Returns: Tibble with matching studies

├── study_id          : Character
├── analysis_id       : Character
├── metabolite_name   : Character
├── refmet_name       : Character
├── analysis_type     : Character
├── ms_type           : Character
├── ionization        : Character
├── chromatography_type : Character
├── species           : Character
├── sample_source     : Character
└── [additional study metadata]

`search_by_mass()`

Purpose: Search compounds by accurate mass

Parameters:

search_by_mass(
  client,                    # mw_rest_client object
  db,                        # Character - "MB", "LIPIDS", "REFMET"
  mz,                        # Numeric - Mass-to-charge ratio
  ion_type,                  # Character - "M+H", "M-H", "M+Na", etc.
  tolerance,                 # Numeric - Mass tolerance (Daltons)
  format = "json"           # Character - "json" or "txt"
)

REST Endpoint: GET /moverz/{db}/{mz}/{ion_type}/{tolerance}[/{format}]

Returns: Tibble with matching compounds

├── refmet_name       : Character
├── formula           : Character
├── exactmass         : Numeric
├── regno             : Character
├── pubchem_cid       : Character
├── kegg_id           : Character
├── mass_difference   : Numeric
└── lipid_category    : Character (for LIPIDS db)

6. Mass Spectrometry Tools

`calculate_exact_mass()`

Purpose: Calculate exact mass for lipid species

Parameters:

calculate_exact_mass(
  client,                    # mw_rest_client object
  lipid_abbrev,             # Character - Lipid abbreviation (e.g., "PC(34:1)")
  ion_type                  # Character - Ion type (e.g., "M+H", "M-H")
)

REST Endpoint: GET /moverz/exactmass/{lipid_abbrev}/{ion_type}

Returns: Tibble with calculated mass

├── lipid_abbreviation : Character
├── ion_type          : Character
├── exactmass         : Numeric
├── formula           : Character
└── adduct_mass       : Numeric

7. Utility Functions

`response_to_df()`

Purpose: Convert API responses to tibbles

Parameters:

response_to_df(
  response        # List - Parsed API response
)

Input Types Handled:

Flat named lists: list(name = "value", id = 123)
Row-based responses: list(Row1 = list(...), Row2 = list(...))
Nested DATA responses: list(metadata..., DATA = data.frame(...))
Lists of lists: list(list(...), list(...))

Returns: Tibble (structure depends on input type)

`flatten_entry()`

Purpose: Flatten metabolite entries with nested sample data

Parameters:

flatten_entry(
  entry           # List - Single metabolite entry with DATA field
)

Required Entry Structure:

entry:
├── study_id          : Character (optional)
├── analysis_id       : Character (optional)
├── analysis_summary  : Character (optional)
├── metabolite_name   : Character (optional)
├── metabolite_id     : Character (optional)
├── refmet_name       : Character (optional)
├── units             : Character (optional)
└── DATA              : Data.frame (required)
    ├── sample1       : Numeric
    ├── sample2       : Numeric
    └── [more samples]: Numeric

Returns: Single-row tibble with flattened structure

`list_endpoints()`

Purpose: Display available API endpoints

Parameters:

list_endpoints(
  client          # mw_rest_client object (for method dispatch)
)

Returns: NULL (called for side effects - prints to console)

API Endpoint Mapping

Complete REST API Endpoint Reference

Function	HTTP Method	Endpoint Pattern	Description
`get_study_summary()`	GET	`/study/study_id/{id}/summary[/{format}]`	Study metadata
`get_study_factors()`	GET	`/study/study_id/{id}/factors`	Experimental factors
`get_study_metabolites()`	GET	`/study/study_id/{id}/metabolites`	Metabolite list
`get_study_data()`	GET	`/study/study_id/{id}/data`	Complete data matrix
`get_compound_by_regno()`	GET	`/compound/regno/{regno}/{fields}[/{format}]`	Compound by registry number
`get_compound_by_pubchem_cid()`	GET	`/compound/pubchem_cid/{cid}/{fields}[/{format}]`	Compound by PubChem CID
`get_compound_classification()`	GET	`/compound/{id_type}/{id}/classification`	Compound taxonomy
`download_compound_structure()`	GET	`/compound/{id_type}/{id}/{format}`	Structure files
`get_refmet_by_name()`	GET	`/refmet/name/{name}/{fields}`	RefMet information
`standardize_to_refmet()`	GET	`/refmet/match/{name}/name`	Name standardization
`get_all_refmet_names()`	GET	`/refmet/name`	All RefMet names
`search_metstat()`	GET	`/metstat/{param1};{param2};...;{param8}`	Multi-criteria search
`search_by_mass()`	GET	`/moverz/{db}/{mz}/{ion_type}/{tolerance}[/{format}]`	Mass-based search
`calculate_exact_mass()`	GET	`/moverz/exactmass/{lipid}/{ion_type}`	Exact mass calculation

Parameter Value Specifications

Database Identifiers

Study IDs: - Format: "ST" + 6-digit number (e.g., “ST000001”) - Special: "ST" returns all studies

Registry Numbers: - Format: Numeric string (e.g., “1”, “123”) - Used in Metabolomics Workbench internal system

PubChem CIDs: - Format: Numeric string (e.g., “5793”) - Links to PubChem database

Analysis Types

Valid values: "LCMS", "GCMS", "GCMS_TMS", "HILIC", "RP", "NMR", "MS", "MSn"

Ion Types

Common values: "M+H", "M-H", "M+Na", "M+K", "M+NH4", "M+2H", "M-2H", "M+H-H2O"

Species

Common values: "Human", "Mouse", "Rat", "Yeast", "E. coli", "Arabidopsis", "Drosophila"

Sample Sources

Common values: "Blood", "Urine", "Tissue", "Cell", "Liver", "Brain", "Muscle", "Plasma", "Serum"

Chromatography Types

Valid values: "HILIC", "RP", "GC", "Ion-pair", "RPLC", "Normal phase"

Data Flow Schema

Data flow schema

Error Handling Schema

HTTP Status Codes

200: Success
400: Bad Request (invalid parameters)
404: Not Found (invalid ID/endpoint)
500: Internal Server Error
503: Service Unavailable

Error Response Structure

API Error Response:
├── status_code       : Numeric
├── error_message     : Character
└── request_url       : Character (for debugging)

R Error Handling:
├── Parameter validation (before API call)
├── HTTP error catching (during API call)
├── Response parsing errors (after API call)
└── Informative error messages (user-friendly)

Common Error Scenarios

Invalid Study ID: Returns empty result or 404
Invalid Compound ID: Returns empty result
Network Issues: Automatic retry (3 attempts)
Malformed Parameters: Validation errors before API call
API Rate Limiting: Built-in backoff and retry

Performance Considerations

Caching Strategy

Cache Key Structure: "{endpoint_url}_{parameters_hash}"
Cache Location: {cache_dir}/httr2_cache/
Cache Expiration: Session-based (temporary directory)

Rate Limiting

Built-in: 3 retry attempts with exponential backoff
Recommended: 1-2 second delays between batch requests
API Limits: Not officially documented, but be respectful

Memory Usage

Function	Typical Size	Notes
`get_study_summary("ST")`	~10-50 MB	All studies metadata
`get_all_refmet_names()`	~5-20 MB	Complete RefMet database
`get_study_data()`	Varies	Can be very large (>100MB)
Individual compound queries	<1 MB	Small responses

Integration Patterns

Tidyverse Integration

All functions return tibbles compatible with dplyr, ggplot2, and other tidyverse packages:

# Chaining operations
result <- client %>%
  get_study_summary() %>%
  filter(grepl("Human", study_title)) %>%
  slice_head(n = 10)

Bioconductor Integration

While the package doesn’t return Bioconductor core classes, the tibble outputs can be easily converted:

# Convert to SummarizedExperiment (example)
study_data <- get_study_data(client, "ST000001")
# ... conversion code would go here

Session Info

sessioninfo::session_info()

## ─ Session info ───────────────────────────────────────────────────────────────
##  setting  value
##  version  R version 4.5.1 (2025-06-13)
##  os       Ubuntu 24.04.3 LTS
##  system   x86_64, linux-gnu
##  ui       X11
##  language en
##  collate  C.UTF-8
##  ctype    C.UTF-8
##  tz       UTC
##  date     2025-09-01
##  pandoc   3.1.11 @ /opt/hostedtoolcache/pandoc/3.1.11/x64/ (via rmarkdown)
##  quarto   NA
##
## ─ Packages ───────────────────────────────────────────────────────────────────
##  package     * version date (UTC) lib source
##  bslib         0.9.0   2025-01-30 [1] RSPM
##  cachem        1.1.0   2024-05-16 [1] RSPM
##  cli           3.6.5   2025-04-23 [1] RSPM
##  desc          1.4.3   2023-12-10 [1] RSPM
##  digest        0.6.37  2024-08-19 [1] RSPM
##  evaluate      1.0.5   2025-08-27 [1] RSPM
##  fastmap       1.2.0   2024-05-15 [1] RSPM
##  fs            1.6.6   2025-04-12 [1] RSPM
##  htmltools     0.5.8.1 2024-04-04 [1] RSPM
##  jquerylib     0.1.4   2021-04-26 [1] RSPM
##  jsonlite      2.0.0   2025-03-27 [1] RSPM
##  knitr         1.50    2025-03-16 [1] RSPM
##  lifecycle     1.0.4   2023-11-07 [1] RSPM
##  pkgdown       2.1.3   2025-05-25 [1] any (@2.1.3)
##  R6            2.6.1   2025-02-15 [1] RSPM
##  ragg          1.4.0   2025-04-10 [1] RSPM
##  rlang         1.1.6   2025-04-11 [1] RSPM
##  rmarkdown     2.29    2024-11-04 [1] RSPM
##  sass          0.4.10  2025-04-11 [1] RSPM
##  sessioninfo   1.2.3   2025-02-05 [1] any (@1.2.3)
##  systemfonts   1.2.3   2025-04-30 [1] RSPM
##  textshaping   1.0.1   2025-05-01 [1] RSPM
##  xfun          0.53    2025-08-19 [1] RSPM
##  yaml          2.3.10  2024-07-26 [1] RSPM
##
##  [1] /home/runner/work/_temp/Library
##  [2] /opt/R/4.5.1/lib/R/site-library
##  [3] /opt/R/4.5.1/lib/R/library
##
## ──────────────────────────────────────────────────────────────────────────────

This schema provides the complete technical specification for all mwbenchr functions and their interaction with the Metabolomics Workbench REST API.

mwbenchr API Schema Documentation

Overview

Function Categories

1. Client Management

mw_rest_client()

2. Study Functions

get_study_summary()

get_study_factors()

get_study_metabolites()

get_study_data()

3. Compound Functions

get_compound_by_regno()

get_compound_by_pubchem_cid()

get_compound_classification()

download_compound_structure()

4. RefMet Functions

get_refmet_by_name()

standardize_to_refmet()

get_all_refmet_names()

5. Search Functions

search_metstat()

search_by_mass()

6. Mass Spectrometry Tools

calculate_exact_mass()

7. Utility Functions

response_to_df()

flatten_entry()

list_endpoints()

API Endpoint Mapping

Complete REST API Endpoint Reference

Parameter Value Specifications

Database Identifiers

Analysis Types

Ion Types

Species

Sample Sources

Chromatography Types

Data Flow Schema

Error Handling Schema

HTTP Status Codes

Error Response Structure

Common Error Scenarios

Performance Considerations

Caching Strategy

Rate Limiting

Memory Usage

Integration Patterns

Tidyverse Integration

Bioconductor Integration

`mwbenchr` API Schema Documentation

`mw_rest_client()`

`get_study_summary()`

`get_study_factors()`

`get_study_metabolites()`

`get_study_data()`

`get_compound_by_regno()`

`get_compound_by_pubchem_cid()`

`get_compound_classification()`

`download_compound_structure()`

`get_refmet_by_name()`

`standardize_to_refmet()`

`get_all_refmet_names()`

`search_metstat()`

`search_by_mass()`

`calculate_exact_mass()`

`response_to_df()`

`flatten_entry()`

`list_endpoints()`
