πŸ”¬ Introduction

BioGA is an R package implementing a genetic algorithm (GA) designed for multi-objective optimization on genomic data. It can be used to:

  • select gene signatures
  • optimize biomarker panels
  • balance objectives like expression distance, sparsity, or custom criteria

This vignette walks through an example using real-world-like gene expression data and demonstrates:

βœ… GA initialization

βœ… Evolution over generations

βœ… Fitness convergence

βœ… Visualizations of population diversity


πŸ“ˆ Prepare data

We’ll simulate realistic gene expression data:

set.seed(123)
n_genes <- 50
n_samples <- 20

# Simulate two classes: cases and controls
class_labels <- rep(c("Control", "Case"), each = 10)
genomic_data <- matrix(rnorm(n_genes * n_samples, mean = 5, sd = 2),
    nrow = n_genes, ncol = n_samples)

# Introduce differential expression in 10 genes for "Case"
genomic_data[1:10, class_labels == "Case"] <-
    genomic_data[1:10, class_labels == "Case"] + 3

rownames(genomic_data) <- paste0("Gene", 1:n_genes)
colnames(genomic_data) <- paste0("Sample", 1:n_samples)

pheatmap(genomic_data,
    cluster_rows = TRUE, cluster_cols = TRUE,
    main = "Simulated Gene Expression Data")


βš™ Run the genetic algorithm

We define parameters and run BioGA:

result <- bioga_main_cpp(
    genomic_data = genomic_data,
    population_size = 30,
    num_generations = 50,
    crossover_rate = 0.9,
    eta_c = 20.0,
    mutation_rate = 0.1,
    num_parents = 20,
    num_offspring = 20,
    num_to_replace = 10,
    weights = c(1.0, 0.5),
    seed = 42
)
#> Current front size: 1
#> Current front size: 1
#> Current front size: 1
#> Current front size: 1
#> Current front size: 1
#> Current front size: 1
#> Current front size: 1
#> Current front size: 1
#> Current front size: 1
#> Current front size: 1
#> Current front size: 1
#> Current front size: 1
#> Current front size: 1
#> Current front size: 1
#> Current front size: 1
#> Current front size: 1
#> Current front size: 1
#> Current front size: 1
#> Current front size: 1
#> Current front size: 1
#> Current front size: 1
#> Current front size: 1
#> Current front size: 1
#> Current front size: 1
#> Current front size: 1
#> Current front size: 1
#> Current front size: 1
#> Current front size: 1
#> Current front size: 1
#> Current front size: 1
#> Current front size: 1
#> Current front size: 1
#> Current front size: 1
#> Current front size: 1
#> Current front size: 1
#> Current front size: 1
#> Current front size: 1
#> Current front size: 1
#> Current front size: 1
#> Current front size: 1
#> Current front size: 1
#> Current front size: 1
#> Current front size: 1
#> Current front size: 1
#> Current front size: 1
#> Current front size: 1
#> Current front size: 1
#> Current front size: 1
#> Current front size: 1
#> Current front size: 1

πŸ“Š Visualize convergence of fitness

Let’s compute and plot how the best fitness evolved.

# Since BioGA currently does not return fitness history,
# let’s re-run manually to track convergence:

track_fitness <- function(...) {
    pop <- initialize_population_cpp(...)
    best_fit <- c()
    for (g in 1:50) {
        fit <- evaluate_fitness_cpp(genomic_data, pop, weights = c(1.0, 0.5))
        best_fit <- c(best_fit, min(fit[, 1])) # Track expression objective
        parents <- selection_cpp(pop, fit, 20)
        offspring <- crossover_cpp(parents, 20)
        mutated <- mutation_cpp(offspring, 0.1, g, 50)
        fit_off <- evaluate_fitness_cpp(genomic_data, mutated, c(1.0, 0.5))
        pop <- replacement_cpp(pop, mutated, fit, fit_off, 10)
    }
    best_fit
}

fitness_trace <- track_fitness(genomic_data, 30, 42)
#> Current front size: 1
#> Current front size: 1
#> Current front size: 1
#> Current front size: 1
#> Current front size: 1
#> Current front size: 1
#> Current front size: 1
#> Current front size: 1
#> Current front size: 1
#> Current front size: 1
#> Current front size: 1
#> Current front size: 1
#> Current front size: 1
#> Current front size: 1
#> Current front size: 1
#> Current front size: 1
#> Current front size: 1
#> Current front size: 1
#> Current front size: 1
#> Current front size: 1
#> Current front size: 1
#> Current front size: 1
#> Current front size: 1
#> Current front size: 1
#> Current front size: 1
#> Current front size: 1
#> Current front size: 1
#> Current front size: 1
#> Current front size: 1
#> Current front size: 1
#> Current front size: 1
#> Current front size: 1
#> Current front size: 1
#> Current front size: 1
#> Current front size: 1
#> Current front size: 1
#> Current front size: 1
#> Current front size: 1
#> Current front size: 1
#> Current front size: 1
#> Current front size: 1
#> Current front size: 1
#> Current front size: 1
#> Current front size: 1
#> Current front size: 1
#> Current front size: 1
#> Current front size: 0
#> Warning: No non-dominated individuals found.     Using full population for selection.
#> Current front size: 1
#> Current front size: 1
#> Current front size: 1

qplot(1:50, fitness_trace, geom = "line") +
    labs(x = "Generation", y = "Best Fitness (Expression Diff.)",
        title = "Convergence of Best Fitness Across Generations")


🎨 Population diversity heatmap

Visualize population at final generation

pheatmap(result$population,
    main = "Final Population of Individuals",
    cluster_rows = TRUE, cluster_cols = TRUE)


🧬 Compare gene selection frequency

gene_selection_freq <- colMeans(result$population != 0)

barplot(gene_selection_freq, las = 2,
        main = "Frequency of Gene Selection in Final Population",
        ylab = "Selection Frequency")


🌐 Network constraint example (optional)

If you had a network, e.g.Β co-expression network:

network_mat <- matrix(runif(n_genes^2, 0, 1), nrow = n_genes)
diag(network_mat) <- 0

mutated_with_net <- mutation_cpp(result$population,
    mutation_rate = 0.1,
    iteration = 10,
    max_iterations = 50,
    network = network_mat)

pheatmap(mutated_with_net,
    main = "Population After Mutation with Network Constraint")


πŸ“Œ Summary

In this vignette, we:

  • simulated realistic genomic data
  • ran BioGA for multi-objective optimization
  • tracked fitness convergence
  • visualized population diversity and gene selection

➑ Next steps

You can:

βœ… Replace simulated data with real RNA-seq or microarray data

βœ… Define custom network constraints (e.g.Β from STRING or BioGRID)

βœ… Extend objectives (e.g.Β clinical outcome correlation)


πŸ’‘ Final tip

For larger datasets, we recommend:


πŸ“ How to use this vignette

Save it as vignettes/bioga-demo.Rmd, and generate with:

devtools::build_vignettes()

βœ‰ Want help improving this further?

πŸ‘‰ Contact me:

Session Info
sessioninfo::session_info()
